Cat® Multi-Processors accept multiple interchangeable jaws for a wide range of demolition tasks. Faster cycle times get your jobs done quicker. Greater power means taking on bigger jobs. Quick jaw change gives you the right tool for the task at hand, without slowing you down. All built on a durable, easy to maintain platform.
Cat® Multi-Processors accept multiple interchangeable jaws for a wide range of demolition tasks. Faster cycle times get your jobs done quicker. Greater power means taking on bigger jobs. Quick jaw change gives you the right tool for the task at hand, without slowing you down. All built on a durable, easy to maintain platform.

Brochures and Spec Sheets

Gallery

MP324 Shear Jaw MP324 Shear Jaw MP324 Shear Jaw MP324 Shear Jaw MP324 Shear Jaw MP324 Shear Jaw MP324 Shear Jaw

Specifications

Specification Value Unit
Cycle Time - Open 1.8 s
Cycle Time - Close 1.2 s
Cutting Force - Blade Throat 669.5 Sh Ton
Cutting Force - Blade Center 274.8 Sh Ton
Cutting Force - Blade Tip 149.7 Sh Ton
Jaw Circuit - Max. Oil Pressure 4786 psi
Jaw Circuit - Max. Oil Flow 59.4 gpm
Rotation Circuit - Max. Oil Pressure 2031 psi
Rotation Circuit - Max. Oil Flow 10.6 gpm
Jaw Depth 24.0 in
Cutter Length 19.5 in
Jaw Opening - Maximum 15.5 in
Jaw Width - Fixed 12.3 in
Jaw Width - Moveable 3.7 in
Width 31.2 in
Length 82.0 in
Height 55.9 in
Weight - Housing, Jaw and Bracket 5729.8 lb
Weight - Jaw Only 2103.2 lb
Excavator Minimum
Excavator Maximum
