CB2.7

Cat

The CB2.7 is a 2.7 to 3 metric ton compactor with 1200 mm (47 in) drums. It's a versatile machine that can be used as the only vibratory roller on small sized jobs or on larger jobs as a support roller for high-production rollers. Its high amplitude and drum width give it the capacity to achieve a tons-per-day production rate that make it an excellent match for shoulders, small parking lots, lane additions, or other similar sized jobs.

Brochures and Spec Sheets

Gallery

Specifications

Specification	Value	Unit
Standard Operating Weight with ROPS	5936	lb
Maximum Weight at Front Drum	2861	lb
Maximum Operating Weight with ROPS	5936	lb
Maximum Weight at Rear Drum	1398	lb
Static Linear Load	60.6	lb/in
Compaction Width	47.2	in
Turning Radius - Outside Drum Edge	3740	mm
Drum Offset	2	in
Travel Speed - Maximum	7.5	mile/h
Static Linear Load	70.6	lb/in
Turning Radius - Inside Drum Edge	100	in
Curb Clearance	17.8	in
Ground Clearance	11.2	in
Engine Power (1)	48.2	hp
Frequency
Engine Model
Drum Diameter	28.3	in
Overall Width	51.7	in
Height - ROPS	70.8	in
Overall Length	99.2	in
Drum Width	47.2	in
Wheel Base	70.9	in
Frequency	3840	V/mm
Centrifugal Force - Maximum	7929	lb
Nominal Amplitude - High	0.02	in
Fuel Tank Capacity	14.37	gal (US)
Water Spray Tank Capacity	52.8	gal (US)

Standard Equipment

OPERATOR ENVIRONMENT
COMPACTON SYSTEM
POWERTRAIN
TECHNOLOGY
ELECTRICAL
OTHER

Optional Equipment

OPERATOR ENVIRONMENT
COMPACTON SYSTEM
POWERTRAIN
TECHNOLOGY
ELECTRICAL
OTHER
